Liquid Transfer Food Grade Pumps For Brewing / Sanitary Stainless Steel Centrifugal Pump

Food Grade Pumps For Brewing Application

Applicable to the fields of food, dairy, beverage, pharmacy, cosmetic etc industry.

1. Chemical Industry: Fat, Dissolvent, Resin, Paint, Pigment, Oil Agent etc.
2. Food Industry: Yogurt, Ice Cream, Cheese, Soft Drink, Fruit Jelly, Ketchup, Oil, Syrup, Chocolate etc.
3. Daily Chemicals: Facial Foam, Hair Gel, Hair Dyes, Toothpaste, Shampoo, Shoe Polish etc.
4. Pharmacy: Nutrition Liquid, Chinese Traditional Patent Medicine, Biological Products etc.

Food Grade Pumps For Brewing Features

The high performances and energy-saving performance of our pumps originate from the inside geometrical features, so that the excellent fluid features and simple CIP are ensured, and the requirements for no-fault operation and low maintenance are guaranteed with the solid pump structure.

Food Grade Pumps For Brewing avoids disadvantages in all design details, such as the precise balancing design, installation of the booster, and outside spring of the shaft seal(without using the inside spring).

Food Grade Pumps For Brewing Technical parameters

Maximum inlet pressure:0.5MPa Temperature range:-10℃+140℃(EPDM)

Noise level(at 1m):60-85dB(A)

Washable seal Hydraulic pressure: maximum 0.1MPa Water volume:0.25-0.5L/min Double end seal Hydraulic pressuremaximum 0.1MPa Water volume:0.25-0.5L/min

GKH technical data (4KW)

A|B|C|D|E|F|GH|K|J|R|P |KG

|115 |290 |179|274 |53 |162/227|112|206 | 290/345 | 227|107|357/417|67

Medium:20℃ clean water

Rotating Speed:2900RPM

Impeller diameter:

Maximumφ180mm

Miniumφ163mm

Emor:±5%

Frequency:50Hz

Inlet Diameter:D1φ63/51mm

Outlet Diameter:D2φ51/38mm

Food Grade Pumps For Brewing Details
